Waste Heat Recycling HRSG Heat Recovery Steam Generator Natural Circulation

Brand Name : HD Boiler

Model Number : HRSG Boiler

Certification : ISO9001,ASME,Grade A,SGS,EN

Place of Origin : China

MOQ : 1Set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 20 Sets/ Year

Delivery Time : Negotiation

Packaging Details : Seaworthy Packing

Condition : New

Structure : WHRS type

Fuel : Biological

Pressure : Low/High Pressure

Range of Applications : Industrial

Specification : Customized

Manufacturing Level : A

Surface Treatment : Painted

Output : Steam

Water Circulation : Natural Circulation

Contact Now

Greatly reducing dust tail Cement kilns pressure HRSG heat recovery series with ASME standard

Production


Along with sustainable development,recycling economy,energy conservation and low-carbon economy ideas put forward one by one.our cogeneration industry has experienced from scratch,small to large development process.

Cogeneration production process is converted waste heat to electrical energy technology.Cogeneration not only energy,as well as environmentally.Important cogeneration equipment room is HRSG.It uses gas,waste and other working fluid in the heat as a heat source or flammable substance,producing steam for power generation.As the working fluid temperature is not high,so the boiler bulky,consumed more than metal.Mainly used for high-temperature waste heat power.

Technical charateristics


Kiln (AQC) HRSG Features

1, Modular assembly structure, reliable sealing expansion

2, Adopt wear fin tubes, boiler pressure parts life assurance

3, Unique flash technology, the boiler outlet temperature is reduced to below 90ºC

Kiln (SP) HRSG Features

1, Heating surface tubes and headers with privildged connection structure, reducing mechanical shock and vibration

2, By mechanical vibration cleaning mode, continous cleaning mode little impact on system operation

3, Set sealed scraper gray machine, greatly reducing dust tail.

Technical Patameter

Cement production line capacity t/d 1000 2500 5000 10000
Boiler inlet flow Nm3/h Kiln(front) 60000 88000 243000 472000
Kiln(tail) 76000 170000 328000 612000
Boiler inlet gas temperature℃ Kiln(front) 370 360 380 390
Kiln(tail) 360 320~360 330 330
Rated evaporation t/h Kiln(front) 5.8 7.25 24 50
Kiln(tail) 7.5 10~15.8 20~24.6 35.5
Rated steam pressure Mpa Kiln(front) 1.25 1.25 1.25 1.25
Kiln(tail) 1.25 1.25 1.25 1.25
Rated steam temperature℃ Kiln(front) 340 330 350 360
Kiln(tail) 340 300~340 310 310
Boiler structure Kiln(front) Vertical Vertical Vertical Vertical
Kiln(tail) Vertical Vertical and Horizontal Vertical and Horizontal Vertical

Waste Heat Recycling HRSG Heat Recovery Steam Generator Natural Circulation

Waste heat boiler system process description


Drum → down-comer → tube row heat surface → riser → drum(water consumption after the feed pump to add water)

Packaging: our products have standard export package, fumigated wood box, U-steel, steel frame reach to sea transportation requirement.

Shipping: we have our own professional shipping company, make sure the product arrived your destination safely and as soon as possible.

Waste Heat Recycling HRSG Heat Recovery Steam Generator Natural Circulation

Company Indroduction


Established in 1985, Zhangjiagang Hua Dong Boiler Co., Ltd. (trading as HD Boiler), is a professional industrial manufacturer, producing utility boiler,industrial boiler,HRSG boiler and all kinds of boiler parts, such as waterwall panels, economizers, air preheaters, superheaters, headers, spiral fin tubes, H-fin tubes, heat pipes etc. HD Boiler is located in Dong Lai Industrial Park, east suburb of Zhang Jia Gang City. The plant’s location is around 150km Expressway to Shanghai Port
